1. High-Precision Measurement
● X/Y-axis accuracy reaches ≤3+L/200(μm) and 0.0005mm, ensuring reliable and precise measurements.
2. Versatile Magnification Options
● Standard 10X magnification, with optional 20X, 50X, and 100X lenses to accommodate various inspection needs.
3. Large, High-Resolution Projection Screen
● Ø 312mm screen with an effective usage area >Ø 300mm, featuring 360° rotation for flexible measurement.
4. Advanced Data Processing System
● DP300 system supports 2D measurements of points, lines, circles, angles, and distances.
5. Illumination
● 24V/150W halogen lamp for both transmission and reflection illumination, ensuring clear imaging for accurate measurements.
6. User-Friendly Operation
● Forced air cooling system for extended operation time, ergonomic design, and intuitive controls for ease of use.
1. High-Precision Measurement
● X/Y-axis accuracy reaches ≤3+L/200(μm) and 0.0005mm, ensuring reliable and precise measurements.
2. Versatile Magnification Options
● Standard 10X magnification, with optional 20X, 50X, and 100X lenses to accommodate various inspection needs.
3. Large, High-Resolution Projection Screen
● Ø 312mm screen with an effective usage area >Ø 300mm, featuring 360° rotation for flexible measurement.
4. Advanced Data Processing System
● DP300 system supports 2D measurements of points, lines, circles, angles, and distances.
5. Illumination
● 24V/150W halogen lamp for both transmission and reflection illumination, ensuring clear imaging for accurate measurements.
6. User-Friendly Operation
● Forced air cooling system for extended operation time, ergonomic design, and intuitive controls for ease of use.
